High-Quality Modular Structure: Durable, Waterproof, and Versatile

This modular structure is designed for exceptional durability and functionality, combining high-quality steel with robust sandwich panels. It is engineered for easy mobility, convenient transportation, and simple cleaning with water. The structure offers superior reliability, ease of installation, and an aesthetically pleasing design, making it suitable for a wide range of applications.

Dimensions:
2990 mm (117.7 inches) × 6055 mm (238.4 inches) × 2896 mm (114 inches)

• Constructed with steel and steel rock wool sandwich panels
• Easy to move, transport, and clean with water
• Reliable structure with convenient lifting capabilities and an attractive design
• Suitable for various environments and long-term use

Detailed Specifications

1. Top Frame

• Beams:
  • 5530 mm × 2.0 mm (217.7 inches × 0.08 inches) × 2 pieces
  • 2138 mm × 2.0 mm (84.2 inches × 0.08 inches) × 2 pieces
• Corner Brackets:
  • 210 mm × 150 mm (8.3 inches × 5.9 inches) × 4 pieces
• Purlins:
  • 80 mm × 40 mm × 1.2 mm (3.1 inches × 1.6 inches × 0.05 inches)
• Insulation:
  • 18 m² (193.75 sq ft) of glass wool
  • 18 m² (193.75 sq ft) of painted steel sheet (thickness: 0.45 mm / 0.018 inches)

2. Bottom Frame

• Beams:
  • 5530 mm × 2.0 mm (217.7 inches × 0.08 inches) × 2 pieces
  • 2138 mm × 2.0 mm (84.2 inches × 0.08 inches) × 2 pieces
• Corner Connectors:
  • 210 mm × 150 mm (8.3 inches × 5.9 inches) × 4 pieces
• Purlins:
  • 100 mm × 50 mm × 1.2 mm (3.9 inches × 2 inches × 0.05 inches) × 9 pieces

3. Columns

• Columns:
  • 210 mm × 150 mm × 2526 mm (8.3 inches × 5.9 inches × 99.4 inches) × 4 pieces
  • Thickness: 2.0 mm (0.08 inches)

4. Bottom Accessories

• Trough:
  • 50S water trough

5. Floor

• Cement Fiberboard:
  • 18 mm (0.7 inches) thick × 5 pieces

6. PVC Flooring

• Thickness:
  • 1.6 mm (0.06 inches)

7. Door

• Steel Door:
  • Size: 970 mm × 1970 mm (38.2 inches × 77.6 inches)

8. Windows

• PVC Single-Glazed Sliding Windows:
  • Size: 930 mm × 1200 mm (36.6 inches × 47.2 inches) × 2 pieces

9. Wall Panels

• Steel Rock Wool Sandwich Panels:
  • Model: V950
  • Thickness: 0.3 mm / 50 mm (0.012 inches / 2 inches)
  • Density: 50 kg/m³

10. Pipes

• PVC Pipes:
  • Diameter: 50 mm (2 inches)
  • Length: 2750 mm (108.3 inches) × 4 pieces

11. Ceiling

• Suspension Ceiling:
  • Type: 831 model

12. Edge Trimming

• Corner Trims:
  • 4 pieces

13. Accessories

• Hardware:
  • 1 set of bolts and adhesive

14. Accessories

• Skirting Board:
  • Included

15. Electrical System

• Electrical Components:
  • 1 three-prong outlet
  • 3 five-prong outlets
  • 1 switch distribution box
  • 1 industrial outlet
  • Wiring
  • 2 × 36W LED light strips (wiring concealed within interior walls)
