Modular Container with Galvanized Steel Framework: Durable, Portable, and Versatile

Introducing our innovative Modular Container, a versatile and durable solution designed for a wide range of applications. This container combines superior construction with modern aesthetics, offering convenience, flexibility, and reliability. Whether used for storage, temporary housing, or mobile workspaces, our container is built to withstand the elements while providing a comfortable and functional interior.

Dimensions and Specifications

• Standard Container Dimensions:
  • External Dimensions: 5800mm (19.03ft) x 2500mm (8.20ft) x 2450mm (8.04ft)
  • Internal Dimensions: 5650mm (18.54ft) x 2350mm (7.71ft) x 2230mm (7.32ft)
  • Folded Dimensions: 5800mm (19.03ft) x 2500mm (8.20ft) x 440mm (1.44ft)
  • Weight: 1.3T (2866 lbs)

Structural Components

• Frame:
  • Top Beam: Galvanized steel profile tube, 63mm x 80mm x 1.5mm (2.48″ x 3.15″ x 0.059″)
  • Bottom Beam: Galvanized steel profile tube, 63mm x 160mm x 2.0mm (2.48″ x 6.3″ x 0.079″)
  • Side Beams: Galvanized steel profile tube, 63mm x 80mm x 1.5mm (2.48″ x 3.15″ x 0.059″)
  • Cross Beams: Galvanized square tube, 50mm x 50mm x 1.8mm (1.97″ x 1.97″ x 0.071″)
  • End Beams: Galvanized steel profile tube, 63mm x 80mm x 1.5mm (2.48″ x 3.15″ x 0.059″)
  • Corner Connectors: Cast steel joints, 200mm x 100mm x 15mm (7.87″ x 3.94″ x 0.59″)
  • Hinges: Galvanized hinges, 85mm x 115mm x 3mm (3.35″ x 4.53″ x 0.12″) with 304 stainless steel pins
  • Coating: High-gloss enamel for performance and durability
• Roof:
  • External Roof: 104-color steel tiles, 0.5mm thickness
  • Internal Ceiling: 831 ceiling panels, 0.326mm thickness
  • Insulation: Rock wool with a density of 60kg/m³ (3.75 lb/ft³), covering 14.5 sqm (156 sqft)
• Floor:
  • Material: A-grade fire-resistant glass magnesium panels, 15mm thickness
• Walls:
  • Side Walls: Insulated sandwich panels with 0.326mm steel cladding and 50mm rock wool insulation (density 65kg/m³)
  • End Walls: Same as side walls, providing consistent insulation and durability
• Windows and Doors:
  • Windows: Aluminum alloy anti-theft windows (sliding series), 950mm x 1200mm (37.4″ x 47.2″) with insect screens
  • Doors: Folding container-specific anti-theft doors, 860mm x 1980mm (33.86″ x 77.95″)
• Load Capacities:
  • Roof Load: ≥ 50kg/m² (10.2 lbs/sqft)
  • Floor Load: ≥ 150kg/m² (30.5 lbs/sqft)
  • Passage Load: ≥ 200kg/m² (40.6 lbs/sqft)
  • Wall Pressure Resistance: ≥ 80kg/m² (16.2 lbs/sqft)
• Safety and Compliance:
  • Fire Resistance: Certified fire-resistant materials
  • Seismic Resistance: Rated for seismic zone 10
  • Wind Resistance: Rated for wind zone 11

Product Advantages

• Portability and Convenience: Easy to transport and install, offering flexible space utilization suitable for various environments.
• Durability and Protection: Waterproof, soundproof, and insulated, ensuring a comfortable interior regardless of external conditions.
• Aesthetic Design: Available in diverse and attractive designs to match any setting.
• Safety and Reliability: Built with high-quality materials and stringent safety standards, ensuring long-term performance and peace of mind.
